Features

• All stainless construction
• CS and VN series in 304SS
• Compact close-coupled design
• Easy installation
• Easy plug-in type wiring connections
• Sealed motor
• Double mechanical seal
• Heavy duty motor shaft

Applications

• Domestic water supply
• Pressure boosting
• Irrigation
• Fountains
• Septic effluent pumping
• Water distribution

Specifications

• Capacities up to; 7.5 m³/h (CS 3-5), 14m³/h (VN 9)
• Heads up to 11 Bar (110 metres, VN-9)
• Maximum working pressure: 10 Bar (CS 3-5) 15 Bar (VN 9)
• Discharge size: 1.25 inches BSPP
• Maximum immersion: 20 m
• Class F insulation, IP68 protection
• Duty rating: Continuous either vertical or horizontal up to maximum ambient temperature of 40 °C
• Maximum starts per hour: 20
• Level control included (1 phase)
• 20 m power cable type H07RN F supplied with AU/NZ 2-3 pin plug
• Maximum Allowable sand or particles: 50 gr/m³ up to 2mm
• Liquid Tempertaure Range: -5°C to 40°C
• Double Mechanical Seal seperated by FDA approved oil (VN series)
